LCA-SQ
The LCA-SQ is a lightweight aluminum lifting column designed for specialized applications such as caravans and tatami setups. Its exceptionally short built-in length and low weight make it ideal for compact, mobile environments. Featuring an integrated actuator, the LCA-SQ is fully compatible with Logicdata’s Dynamic Motion System, offering seamless integration and precise performance.
- Variable height adjustment from 304 to 676 mm
- Driving speed up to 34 mm/s
- ISP (Intelligent System Protection)
- Dynamic load 50kg
- Static load 120kg
Technical Data
Input Rating | 12V/24V DC |
Lifting Capacity | 500 N |
Speed | 34 mm/s |
Stroke | 370 mm |
Installation Length | 304 mm |
